Pneumatic high temperature control valve consists of multi-spring pneumatic diaphragm actuator and low flow resistance high temperature control valve body. The body flow channel of pneumatic high temperature globe control valve is S streamline type. It has the advantages of compact structure,light weight,sensitive action,small pressure drop loss,large valve capacity,accurate flow characteristics and convenient maintenance.The pneumatic high-temperature control valve is especially suitable for occasions where the leakage is small, the pressure difference between the valve is small and the temperature is high.

Valve Material

• Body Material WCB, CF8, CF8M, CF3M, etc
• Gasket Material metal graphite gasket/PTFE
• Trim Material 304, 316, 316L, etc
• Spool And Seat Material 304, 316, 316L,  etc
• Bonnet Material WCB, CF8, CF8M, CF3M, etc
• Stem Material 304, 316, 316L,  etc

Design Feature

• Trim Features top guided unbalanced Internals, quick release cage structure
• Body Type straight-through, angled
• Spool Form single seat type, sleeve type, cage type
• Bonnet Form standard, heat sink, low temperature, bellows
• Gland Type bolt pressing type
• Flow Characteristics equal percentage, linear, quick opening
